Minneapolis-Moline ZB

Finding Parts

We don't publish part numbers we can't verify against factory literature. The authority for this model's part numbers is its factory parts catalog; interchange is serial- and configuration-dependent, so always confirm against the parts book before buying.

Engine-family parts

This model uses the 3.4 L Four-Cylinder (Gas & Diesel), shared with 445. Many engine-family components are common across these models — verify fitment against the parts catalog, as serial- and configuration-specific variations exist.

Documented parts

Cataloged Minneapolis-Moline part numbers documented for this model. Applications vary by serial, year, and configuration — confirm against your parts book before ordering.

Bearing

• 10A199 — Throwout bearing
• RE362 — Z-engine front main bearing
• RE363 — Z-engine rear main bearing

Belt

• RE684 — Fan & water-pump belt

Carburetor

• TSX-97 — Marvel-Schebler carburetor (MM# RE733C)

Clutch

• 10P355 — 10" organic clutch plate, solid center
• 10P369 — 11" clutch, 10-spline, 1.5" spline dia.
• JT9019 — One-piece driving plate & friction discs, 63-tooth
• 10A3743 — Pressure plate, 11", three levers, 9 springs

Decal

• 10D1394 — Decal set

Engine Bearing

• EE5353 — Rear main bearing, standard (206 engine)
• 10A8420 — Rod bearing set, standard (206B-4 engine)

Gasket

• 10A4137 — Transmission cover gasket

Hose

• 10A326 — Upper radiator hose

Oil Filter

• RE5599 — Oil filter

Piston

• 60P36462360 — 3.625"+0.020 aluminum piston w/ pin, rings, retainers
• 60P36862360 — 3.625"+0.040" aluminum piston
• 60P38002363 — 3.8" bore 700-gram forged racing piston & HP pin
• 2-10R795 — Four sets of 0.040" over-rings for 10R792 piston
• 60R3686 — Ring set (3.625"+0.040")
• 60R3646 — Ring set for 60P36462360 piston

Seal

• 10A21466 — Rear Engine Crankshaft Seal
